SPECIFICHE
Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, CSMA/CA with ACK
Wireless Signal Rates With Automatic Fallback 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Frequency Range 2.4-2.4835GHz
Wireless Transmit Power 20dBm(max. EIRP)
Modulation Type OFDM/CCK/16-QAM/64-QAM
Receiver Sensitivity 270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Security 64/128/152 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Support Operating System Windows 2000/XP/Vista
Hardware Specification
Interface 32-bit PCI
Antenna Type Omni Directional, Detachable
Antenna Power 2 x 2dBi
Certifications CE, FCC
Operating temperature 0°C~40°C
Storage temperature -40°C~70°C
Relative humidity 10% ~ 90%, non condensation
Storage Humidity 5%~95% non-condensing
Dimensions 5.2 × 4.8 × 0.9 in. (133 × 121 × 22 mm)
